JLG Liftlux 203-24
The JLG Liftlux 203-24 triple scissor arm design provides the elevated platform with a unique stiffness and lateral rigidity. The machine provides more comfort for the user, and an increased work load capacity.
Interested in hiring this product?
Mainline Hire
Based on 15 Google Reviews
Specifications
Download Data sheet
Max Working Height |
22.3m |
Max Platform Height |
20.3m |
Overall Width |
2.4m |
Overall Length |
4.8m |
Stowed Height |
2.96m |
Platform Capacity |
750kg |
Gross Machine Weight |
11400kg |
Stowed Gradeability |
30% |
Specifications may be subject to change – clarification should be sought at point of hire.
Features
-
Four-wheel drive (4WD)
-
Fold-down / drop-down handrails
-
Removable platform console box
-
Lanyard attach points
-
Load sensing system
-
Hydraulic differential lock
-
Steel mesh scissor arm guards
-
3 degree tilt indicator light with cut-out
-
Manual descent system
-
Horn
-
Single hydraulic powered deck extension
-
Self-closing gate
-
Platform console function status LED’s
-
Proportional drive control
-
Two speed drive selection
-
Nivolux self-levelling hydraulic jacks
-
Foam-filled lug tread tyres
-
Ground control selector switch with key lock
-
Hour-metre
-
Travel alarm
