9.75m Hybrid Rough Terrain Scissor Lift – Skyjack SJ6832RTE 4×4

Skyjacks’s Compact Series Rough Terrain Scissor Lifts offer the same industry leading rugged, robust, and reliable scissor lifts that have made Skyjack famous.

The SJ 6832 RTE comes equipped with an exclusive cross over symmetrical 4WD system for superior traction. Featuring  45% gradeability, these machines can meet the needs of the most challenging job site terrain. Standard features also include an easy to use 1.52m roll out extension deck, which can be secured in multiple positions for increased platform space and improved reach capabilities.

This model is driveable at full height with the roll out deck fully extended. A low stowed height is ideal for loading and unloading tools and materials.

Download PDF datasheet

Features

  • Crossover symmetrical four-wheel drive (4WD)
  • Driveable at full height with roll out deck fully extended
  • Multiple wet disc spring applied hydraulic release brakes
  • Roll out extension deck
  • 16hp AC Electric motor with motor controller
  • 48V 250Ah Battery pack
  • Hybrid Diesel Power Pack
  • Relay-based control system
  • Foam filled grip lug non-marking tyres
  • AC Power to platform
  • Tilt alarm with drive & lift cut-out
  • Overload sensing system
  • Lowering warning system
  • Operator horn
  • Hinged railing system
  • Lanyard attachment point

Specification

  • Platform Height9.75m
  • Working Height11.75m
  • Lift Capacity454kg
  • Own Weight3778kg
  • Platform Size1.42m x 2.44m
  • Platform Extension1.52m
  • Gradeability45%
  • Travel Speed5.6km/h
  • Power SystemHybrid
