14m Non-Powered Personnel Lift – Dingli AWP14-1000

The Dingli AWP14-1000 is a great addition to our personnel lift fleet. It is designed to be compact but still offer great reach. This makes it the perfect solution for many modern maintenance issues. Its compact design makes it ideal for use in crowded spaces such as shopping centres, airports and train stations.

The AWP14-1000 offers a reach of up to 14 metres, a height that would normally require a larger machine.  Its platform has a safe working load of 135kg, easily enough for an engineer and a sizeable tool box

One innovation that separates the Dingli AWP14-1000 from rival personnel lifts is its tilt back frame. This design reduce the machines overall height while increasing its manoeuvrability. This makes it ideally suited for use in spaces where access is limited by doorways, corridors etc. The machine is designed with solo working in mind. When in transportation mode the caster wheels can be locked to give extra control while the handle can be easily adjusted to reduce user strain.

To insure the Dingli AWP14-1000 is always stable it is fitted with outriggers which automatically adjust to level the machine giving the user a safe secure working platform.

Download PDF datasheet


  • Tilt back frame to reduce the machine height
  • Self-leveling outriggers with sensor system (LED Display)
  • Two controllers operation
  • Leveling indicator
  • Forklift pockets
  • Trunk loading device
  • Outriggers with interlock
  • Emergency lowering system
  • All motion alarm
  • Easy loading
  • Transport tie hole
  • Cylinder holding valve
  • Adjustable pickup rail


  • S.W.L136 kg
  • Max Occupants1
  • Max Working Height14 m
  • Max Platform Height12 m
  • Overall Stowed (Length)1.46 m
  • Overall Length (Tilted Back)3.13 m
  • Overall Width0.75 m
  • Overall Height (Stowed)2.75 m
  • Overall Height (Tilted Back)1.98 m
  • Platform Size0.69m x 0.66 m
  • Up/Down Speed62/47 sec
  • Weight (DC)522 kg
